What Is Low Volume PCB Assembly?
Our Mixed Technology PCB Assembly Capabilities
Altimex combines surface mount and through-hole assembly processes to manufacture PCB assemblies containing a wide range of component types. Each stage is planned around the board layout, component requirements and expected production volume, supporting accurate assembly from prototypes through to repeat production.
Altimex uses automated surface mount assembly equipment for the accurate placement of compact and fine-pitch components. Controlled solder paste application, component placement and reflow soldering support consistent results across prototypes, low-volume batches and repeat production.
Through-hole components are inserted and soldered using controlled manual or automated processes. This method is suited to connectors, transformers, larger components and parts that require strong mechanical connections or additional support.
Surface mount and through-hole components are assembled on the same PCB using a planned production sequence. Our engineers review component placement, soldering requirements and thermal considerations to reduce manufacturing risks and maintain consistent assembly quality.
Mixed technology PCB assemblies are inspected throughout production using visual checks, automated inspection and testing options based on the project requirements. Work is completed in line with IPC-A-610 and IPC-J-STD-001 standards.
Component Sourcing for Low Volume PCB Assembly
Altimex provides component sourcing for low volume PCB assembly, supporting prototype, pre-production and small-batch builds with a managed procurement service. We work with established suppliers to source components that meet the required specification, compliance criteria and delivery schedule, with close attention to availability, lifecycle status and supply risk.
Customers can choose full turnkey sourcing, partial sourcing or supply their own components. Our team reviews the bill of materials, highlights potential shortages and assesses suitable alternatives for approval before production begins. Each part is checked prior to assembly to support traceability, reduce delays and maintain consistent quality across initial and repeat builds.
Altimex provides low volume PCB assembly services for prototype, pre-production and small-batch manufacturing requirements. Our engineers review the PCB design, bill of materials, component availability, assembly method and testing requirements before production begins, helping to identify risks early and keep each build on schedule.
We support surface mount, through-hole and mixed technology assemblies, with flexible component sourcing, inspection and testing available as part of the service. Contact Altimex to discuss your production quantity, technical specification and delivery requirements with our experienced team.
Why Work With Altimex?
30+ Years Of Experience
Fast Turnaround Time
Tailored
Solutions
Building Long-Term Partnerships
Certified & Experienced Team
Our Low Volume PCB Assembly Process
Altimex follows a controlled low volume PCB assembly process to support accuracy, traceability and repeatable build quality. Each project is reviewed by experienced engineers, with production planned around the PCB design, component availability, required quantity and testing specification.
- Design and manufacturing review
- Component sourcing and verification
- Solder paste application
- Automated pick and place assembly
- Reflow soldering
- Through-hole component insertion and soldering
- Inspection and testing
Sectors we support.
Electronics manufacturing for applications where quality, reliability and consistent performance matter.
What Is Low Volume PCB Assembly Used For?
Frequently Asked Questions
What is considered low volume PCB assembly?
Low volume PCB assembly refers to the production of printed circuit board assemblies in smaller quantities. It is commonly used for prototypes, pre-production batches, specialist equipment, replacement boards and products with limited demand.
What are the benefits of low volume PCB assembly?
Low volume production gives businesses greater flexibility over order quantities, design revisions and production schedules. It can reduce the financial risk of placing a large order before a design has completed testing or gained market approval.
Which PCB assembly methods can be used for low volume production?
Low volume PCB builds can use surface mount technology, through-hole assembly or a combination of both methods. The selected process depends on the PCB layout, component types, mechanical requirements and intended application.
Can Altimex support prototypes and repeat production batches?
Yes. Altimex supports prototype assembly, pre-production builds and repeat small-batch orders. Manufacturing data and build records can be reviewed for future orders, supporting consistent workmanship across each production run.
Can components be sourced as part of the assembly service?
Yes. Customers can choose full turnkey sourcing, partial sourcing or supply their own components. Altimex reviews the bill of materials, checks component availability and raises potential supply issues before production begins.
What files are needed for a low volume PCB assembly quote?
Customers will usually need to provide Gerber files, a bill of materials, component placement data and assembly drawings. Testing instructions, workmanship standards and revision details should be supplied where relevant.
How are low volume PCB assemblies inspected and tested?
Inspection may include visual checks, automated optical inspection and project-specific functional testing. The agreed inspection process will depend on the board design, component density, production quantity and application requirements.
Are mixed technology assemblies completed to IPC standards?
Altimex uses controlled assembly practices aligned with recognised standards, including IPC-A-610 and IPC-J-STD-001. Project requirements should be discussed at the quotation stage so the correct workmanship, inspection and documentation criteria can be agreed.
