Mixed Technology PCB Assembly

Altimex provides mixed technology PCB assembly services for businesses across the UK, combining surface mount technology and through-hole assembly within a single production process. We support projects from prototype development through to full production, with flexible component sourcing and assembly options based on each board’s technical requirements. Our experienced engineers and assembly technicians use controlled manufacturing processes, automated equipment and detailed quality checks to maintain accuracy and consistency. Assemblies are completed in line with recognised industry standards, including IPC-A-610 and IPC-J-STD-001.

✓ PCB Manufacturing Specialists
✓ Prototype to Volume Production
✓ UK-Based PCB Manufacturing
✓ Quality-Assured PCB Solutions

Proud to have worked with

What Is Mixed Technology PCB Assembly?

Altimex is a UK electronics manufacturer with more than 30 years of experience in PCB assembly and bespoke electronic production. From its Cheshire facility, the company provides mixed technology PCB assembly for organisations across aerospace, automotive, telecommunications, defence and maritime, supporting projects from early prototypes through to repeat production.

By combining surface mount and through-hole assembly within controlled manufacturing processes, Altimex can produce complex PCB assemblies with consistent quality and traceability. Experienced engineers and technicians oversee each stage of production, helping clients meet technical requirements, manage component sourcing and maintain reliable delivery schedules.

Our Mixed Technology PCB Assembly Capabilities

Altimex combines surface mount and through-hole assembly processes to manufacture PCB assemblies containing a wide range of component types. Each stage is planned around the board layout, component requirements and expected production volume, supporting accurate assembly from prototypes through to repeat production.

Surface Mount Assembly

Altimex uses automated surface mount assembly equipment for the accurate placement of compact and fine-pitch components. Controlled solder paste application, component placement and reflow soldering support consistent results across prototypes, low-volume batches and repeat production.

Plated Through-Hole Assembly

Through-hole components are inserted and soldered using controlled manual or automated processes. This method is suited to connectors, transformers, larger components and parts that require strong mechanical connections or additional support.

Combined Assembly Processes

Surface mount and through-hole components are assembled on the same PCB using a planned production sequence. Our engineers review component placement, soldering requirements and thermal considerations to reduce manufacturing risks and maintain consistent assembly quality.

Inspection and Quality Control

Mixed technology PCB assemblies are inspected throughout production using visual checks, automated inspection and testing options based on the project requirements. Work is completed in line with IPC-A-610 and IPC-J-STD-001 standards.

Component Sourcing for Mixed Technology PCB Assembly

Altimex provides component sourcing for mixed technology PCB assembly, covering both surface mount and through-hole components within one managed procurement process. We work with established suppliers to source parts that meet the required specification, availability and compliance criteria, with close attention to lead times, component lifecycle and supply risk.

Customers can choose full turnkey sourcing or supply selected components themselves. Our team reviews bills of materials, identifies potential availability issues and assesses suitable alternatives for customer approval. Components are checked before production to support traceability, reduce delays and maintain consistent assembly quality across prototype and repeat builds.

Need Mixed Technology PCB Assembly Services?

Altimex provides mixed technology PCB assembly services for projects that require both surface mount and through-hole components on the same board. Our engineers work with you from initial specification through to production, reviewing component requirements, assembly methods, quality standards and delivery times at each stage.

We support prototype, low-volume and repeat production builds, with component sourcing, controlled assembly, inspection and testing available as part of the service. Contact Altimex to discuss your PCB design, bill of materials and production requirements with our experienced team.
